Power Supply 12V-2A
Product: PS12-2A
- Input Voltage : 100-270V AC
- Output Voltage : 24V DC
- Efficiency : 85% @230V AC
- Compact & Sleek Design With Plastic Enclosure
- Size (mm): 90(H) x 22.5(W) x 75(D)
- Protection parameter : Overload , Output short circuit, Over Temperature
| Input Specification: | |
| Supply Voltage | 100 to 270V AC (L-N) 127 to 350V DC |
| Frequency Range | 50/60 Hz |
| AC Current (TYP.) | 0.450A@100V AC 0.24A@270V AC |
| Efficiency (TYP.) | >85%@230VAC |
| Start UP time | <1 sec@230VAC & |
| <3 sec@100VAC (Full Load) | |
| Output Specification: | |
| Output Voltage | 12V DC |
| Output Current | 2A at 12V |
| Ripple & noise | <1% of V out |
| Line & Load Regulation | ±1% |
| Hold UP Time | <60ms at 230VAC & |
| >15ms at 100VAC (Full Load) | |
| LED Indication | |
| LED 1 | Power On |
| Protection: | |
| Input Fused | 2A-250V AC Internal |
| Output Over Load | 110% of rated Output Current protection Protection Type :Hiccup mode;recover automatically after fault condition is removed |
| Output Short Circuit | Hiccup mode when output is shorted;Recovers automatically after fault condition is removed. |
| Over Temperature | Power supply shuts down when the temperature goes above specified limit; |
| Turns on automatically after temperature goes back to Normal operating conditions. | |
| Isolation between Input and Output : |
2.5 KV |
| Environmental | |
| Working Temperature | -25°C to 50°C * De-rate output power at 3w/°C above +50°C Ambient |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 95% RH Non-condensing |
| Mechanical Characteristics | |
| Mounting Type | Din Rail Mount |
| Size | 90 (H) x 22.5 (W) x 75 (D) |
| Material Body | Polycarbonate (PC) |
| Terminal Screw Size | M3.5 |
| Screw Torque (N.m) | 0.5 |
| Wire Gauge (AWG) | 26-14 |
- Robotics
- Elevators
- Automation panel
- Special purpose machine
Product Variant
| Sr.No | Model Number | Input Voltage | Output Voltage | Current Capacity |
| 1 | PS12-2A | 100-270V AC | 12V DC | 2A |
| 2 | PS12-1A | 100-270V AC | 12V DC | 1A |
