| INPUT SPECIFICATION | |
| Input | 4- 20 mA DC |
| Input Inpedance | <100Ω |
| CMRR | >120dp (Typical) |
| Temperature Co-efficient | <100 PPM |
| DIMENSION | |
| Size (mm) | 76 (H) X 28 (W) X 85 (D) |
| OUTPUT SPECIFICATION: | |
| Output | 4 to 20mA DC,0-10V DC (Anyone) |
| Response Type | <150ms |
| Output Inpedance | <500Ω |
| POWER SUPPLY: | |
| Auxiliary Voltage | 100 to 270V AC,50/60Hz |
| Power Consumption ( VA Rating ) | 5VA @230V AC |
| ISOLATION: | |
| Isolation Type | Optical - 3 way |
|
Isolation between |
At least 1.5KV AC for 1 min |
- Field Interface device
- Impedance matching of transmitters and receiver
- Isolation of field signals
- Distribution of signals
- Factory automation
- Powering of field Transmitters
