| INPUT: | |
| Input Current | 50mA to 5AmP AC, (Without CT) CAT III |
| Controlling PF | +0.80(Lag) to -0.80(Lead) |
| Frequency | 50 Hz |
| Min. Operating Current | Selectable Range of up to 50mA to 500mA |
| Operating Voltage | 30 to 290V AC (L-N) CAT III |
| DISPLAY AND KEYS: | |
| Display | 4-Digit, 7-Seg, 0.56”,White Display |
| Keys | SET / ENT, INC, DEC, EXIT |
| DIMENSION: | |
| Size (mm) | 96 (H) X 96 (W) X 54 (D) mm |
| Panel Cutout (mm) | 92 (H) X 92 (W) mm |
| AUXILIARY SUPPLY: | |
| Supply Voltage | 230V AC+20%, 50 Hz |
| Power Consumption | 8VA @ 230 AC MAX |
| ENVIRONMENT CONDITION: | |
| Protection Level (As Per Request) |
IP-65 (Front side) As per IS/IES 60529 : 2001 |
| Operating Temperature | 0°C To 55°C |
| Relative Humidity | Up to 95% RH Non Condensing |
- PF Management using 1 CT Method
- For 3Ø Balanced Industrial Loads
- Energy Monitoring System
- DG Set Panels
- Process Control
- Power Factor Correction Panels
- Commercial Buildings
