Product: PS48V-2.5A

Power 120W
Mounting DIN Rail
Input Voltage : 100-270V AC
Output Voltage : 24V DC
Efficiency > 89% @230V AC
Material: Front Facia (ABS) & Enclosure (Aluminium)
Protection Parameter : Output Overload, OutputOver Voltage , Output short circuit, Over Temperature

Input Specification :
Supply Voltage	100 to 270V AC±10%,(L-N)
Frequency Range	50 / 60Hz
AC Current (TYP.)	2.1A@100V AC, 0.95A@270V AC
Efficiency (TYP.)	>89%@230V AC
Start UP time	<1 sec@230V AC &
Start UP time	<3 sec@100VAC (Full Load)
Output Specification :
Output Voltage	46 - 55V DC
Output Current	2.5A at 48V; 2.2A at 55V
Ripple & noise	<1% of Vout*
Line & Load Regulation	±1%
Hold UP Time	<60ms at 230V AC &
Hold UP Time	>15ms at 100V AC (Full Load)
Protection:
Input Fused	3.15A-250V AC Internal
Output Over Load	110% to 120% of rated output Current protection Protection Type : hiccup mode;recover automatically after fault condition is removed
Output Short Circuit	Hiccup mode when output is shorted;Recovers automatically after fault condition is removed.
Output Over Voltage	62V DC ±1V DC Protection type: Latched: Input AC Power has to be recycled to recover the power supply.
Over Temperature	Power supply shuts down when the temperature goes above specified limit;
Over Temperature	Turns on automatically after temperature goes back to Normal operating conditions.
Isolation between Input and Output :	2.5 KV
Physical :
Mounting Type	Din Rail Mount
Size	105 (H) x 45 (W) x 110 (D)
Material	Front - ABS Enclosure - Aluminium
