Product: PS12-1A

Power 120W
Efficiency > 89% @230V AC
Input Voltage : 100-270V AC
Output Voltage : 24V DC
Material: Plastic Enclosure.
Protection Parameter : Output Overload, Output Over Voltage , Output short circuit, Over Temperature

Input Specification :
Supply Voltage	100 to 270V AC±10%,(L-N)
Frequency Range	50 / 60Hz
AC Current (TYP.)	0.450A@100V AC, 0.24A@270V AC
Efficiency (TYP.)	>85%@230V AC
Start UP time	<1 sec@230V AC &
Start UP time	<3 sec@100VAC (Full Load)
Output Specification :
Output Voltage	12V DC
Output Current	1A at 12V
Ripple & noise	<1% of V out
Line & Load Regulation	±1%
Hold UP Time	<60ms at 230V AC &
Hold UP Time	>15ms at 100V AC (Full Load)
Protection:
Input Fused	2A-250V AC Internal
Output Over Load	110% of rated output Current protection Protection Type : hiccup mode;recover automatically after fault condition is removed
Output Short Circuit	Hiccup mode when output is shorted;Recovers automatically after fault condition is removed.
Over Temperature	Power supply shuts down when the temperature goes above specified limit;
Over Temperature	Turns on automatically after temperature goes back to Normal operating conditions.
Isolation between Input and Output :	2.5 KV
Physical :
Mounting Type	Din Rail Mount
Size	90 (H) x 22.5 (W) x 75 (D)
Material	Polycarbonate
