Multifunction Meter- 4 Line Display
Product: AVH-16
- 1Ø-2W, 3Ø-3W/4W Selectable
- Voltage Measurement 100V to 520kVAC, Secondary 100V to 520V AC
- THD upto 32th Order
- Import Export Energy
- Import Export Energy Measurement
- Pulse & RS-485 Modbus Communication
PARAMETER SPECIFICATION | ||
Input Signal | 3Ø 3 Wire / 3Ø 4Wire / 1Ø 2Wire | |
CT Primary | up to 9999A (Programmable) | |
CT Secondary | 5 Amp/1 Amp selectable | |
PT Primary | 100V to 520kV (Programmable) | |
PT Secondary | 100V to 520V (L-L) (Programmable) | |
PF Avg. & Per Phase | 0.100 - 1.000 | |
Frequency (Hz) | 45.00 - 60.00 Hz | |
Load hours | 9999.59 Hrs/Min | |
No load hours | 9999.59 Hrs/Min | |
On Hour | 9999 Hour | |
RPM | 3600 RPM @ 60 Hz & 2 pole | |
POWER | ||
KW Total | 0.000 - 9999 MW | |
kW Per Phase | 0.000 - 9999 MW | |
kVA Total | 0.000 - 9999 MVA | |
kVA Per Phase | 0.000 - 9999 MVA | |
kVAr Total | 0.000 - 9999 MVAr | |
kVAr Per Phase | 0.000 - 9999 MVAr | |
ENERGY | ||
Import Kwh | 000.000 - 99999999 MWh | |
Export Kwh | 000.000 - 99999999 MWh | |
Net Kwh | 000.000 - 99999999 MWh | |
Total Kwh | 000.000 - 99999999 MWh | |
Kvah Total | 000.000 - 99999999 MVAh | |
Import Kvarh | 000.000 - 99999999 MVArh | |
Export Kvarh | 000.000 - 99999999 MVArh | |
Lag Kvarh | 000.000 - 99999999 MVArh | |
Lead Kvarh | 000.000 - 99999999 MVArh | |
Total Kvarh | 000.000 - 99999999 MVArh | |
DISPLAY & KEY | ||
Display | Upper | 8 Digit, 7 Seg 0.40”,RED LED |
Lower | 4 Digit, 3 Line 7 Seg 0.40”,RED | |
Key | PROGRAM, VAF, POWER, ENERGY, THD% | |
AUXILIARY SUPPLY | ||
Supply voltage | 100 to 270V AC/DC, 50/60Hz | |
Power consumption (VA RATING) | Approx 4 VA @ 230V AC MAX | |
COMMUNICATION | ||
RS-485 MODBUS | ||
ACCURACY | ||
Class 0.5 (Standard) | ||
ENVIRONMENT CONDITION | ||
Operating Temp | 0°C to 55°C | |
Relative Humidity | UP to 95% RH (non-condensing) | |
Protection Level (AS Per Request) | IP-65 (Front side) As per IS/IEC 60529 : 2001 | |
DIMENSION | ||
Size | 96 (H) x 96 (W) x 54 (D) mm | |
Panel Cutout | 92 (H) x 92 (W) mm |
- Control & Relay Panel
- Energy Management System
- DG Set Panels
- LT / HT Panel
- Power Control Center Panels
- Motor Control Center Panels
Product Variant
Part code | Size(H X W X D)mm | Network | Input | Pulse | Communication | Aux Supply | |
EPM-310 | 48 X 96 X 65 | 3Ø/4W | 1 Line Display | 30 to 300V AC (L-N), 50 to 520V AC (L-L) + 5A CT Secondary | Yes | Yes | 100-270V AC |
MFM-13 | 96 X 96 X 54 | 3Ø3W/4W ,1Ø2W, | 3 Line Display | 100V to 520V AC (L-N), 100V to 520KV AC PT Primary + 5A CT Secondary | Yes | Yes | 100-270V AC OR 20-60V DC Factory Set |
MFM-15 | 96 X 96 X 54 | 3Ø3W/4W ,1Ø2W, | 3 Line Display | 100V to 520V AC (L-N), 100V to 520KV AC PT Primary + 5A CT Secondary | Yes | Yes | 100-270V AC |
AVH-14 | 96 X 96 X 54 | 3Ø3W/4W ,1Ø2W, | 4 Line Display | 100V to 520V AC (L-N), 100V to 520KV AC PT Primary + 5A CT Secondary | Yes | Yes | 100-270V AC |
AVH-16 | 96 X 96 X 54 | 3Ø3W/4W ,1Ø2W, | 4 Line Display | 100V to 520V AC (L-N), 100V to 520KV AC PT Primary + 5A CT Secondary | Yes | Yes | 100-270V AC |
As on request can provide 3 Phase CT Module 30A, 60A and 125A along with Ampere Meter |
